Amorphe und Nanokristalline Kerne
Rund und oval gewickelte weichmagnetische Kerne aus nanokristallinem VITROPERM® oder amorphem VITROVAC® bieten niedrige magnetische Verluste über die volle Bandbreite an Permeabilität von µ~700 bis hinauf zu µ>>100.000.
Vorteile:
- F-, R- und Z-förmige Hysterese-Schleifen
- Große Auswahl an Kernabmessungen und Permeabilität
- Hohe Sättigungsmagnetisierung
- Niedrige Temperaturabhängigkeit
- Epoxidharz-Beschichtung oder Kunststoff-Kerntröge
Ringkerne für industrielle EMV Anwendungen
- Kerne mit Epoxidharz-Beschichtung für Betriebstemperaturen bis zu 120 °C
- Kerne im Kunststoff-Kerntrog für Betriebstemperaturen bis zu 130 °C
- Ausgewählte Kernabmessungen sind in unterschiedlicher Permeabilität verfügbar, um ein Optimium aus Dämpfungsverhalten und Sättigungsfestigkeit für die Anwendung zu finden
Ringkerne und Ovalkerne zur Gleichtaktunterdrückung
- Umgebungstemperatur: -40 °C < Ta < +105 °C
- Max. Dauer-Betriebstemperaturen (typabhängig) Top = 130 °C bzw. Top = 150 °C
- Automotive qualifiziert in Anlehnung an AEC-Q200
- Produktion in IATF 16949 zertifizierten VAC Produktionsstätten
- Design unter Berücksichtigung ‚Technischer Sauberkeit‘ nach VDA 19 Part 2 und ZVEI Leitfaden ‚Technische Sauberkeit in der Elektrotechnik‘
- Entwickelt für den Einsatz an der Hochvolt-DC Batterie oder
- Am DC-Ausgang des Antriebsinverters sowie am AC-Ausgang des Antriebsinverters in Hybrid- und Elektrofahrzeugen
Kerne für Stromtransformatoren in elektronischen Energiezählern
Nanokristalline und amorphe Kerne für sehr kleine Amplitudenfehler auch unter DC-Vorspannung
Niedriger und konstanter Leistungsfehler für verschiedene Lastbedingungen
Verschiedene Standardtypen in der Tabelle unten
Kerne für Fehlerstromschutzschalter (FI)
Unsere Expertise für magnetische Materialien und langjährige Anwendungserfahrung hat eine breite Palette an innovativen Lösungen auf Basis nanokristalliner Kerne hervorgebracht. Diese haben insbesondere ihren Weg in den Markt für Fehlerstromschutzschalter gefunden.
Unser Leistungsporfolio umfasst:
- Bestmögliche Auslegung des Kerndesigns in enger Abstimmung mit unseren Kunden
- Technischer Support mit Simulationssoftware für Optimierungen am Schaltungsdesign
- Sonderkonstruktionen auf Anfrage
- Großserien-Kernproduktion an unseren Standorten in der Slowakei und in Malaysia
Ringkerne für industrielle EMV Anwendungen
- Kerne mit Epoxidharz-Beschichtung für Betriebstemperaturen bis zu 120 °C
- Kerne im Kunststoff-Kerntrog für Betriebstemperaturen bis zu 130 °C
- Ausgewählte Kernabmessungen sind in unterschiedlicher Permeabilität verfügbar, um ein Optimium aus Dämpfungsverhalten und Sättigungsfestigkeit für die Anwendung zu finden
Ringkerne und Ovalkerne zur Gleichtaktunterdrückung
- Umgebungstemperatur: -40 °C < Ta < +105 °C
- Max. Dauer-Betriebstemperaturen (typabhängig) Top = 130 °C bzw. Top = 150 °C
- Automotive qualifiziert in Anlehnung an AEC-Q200
- Produktion in IATF 16949 zertifizierten VAC Produktionsstätten
- Design unter Berücksichtigung ‚Technischer Sauberkeit‘ nach VDA 19 Part 2 und ZVEI Leitfaden ‚Technische Sauberkeit in der Elektrotechnik‘
- Entwickelt für den Einsatz an der Hochvolt-DC Batterie oder
- Am DC-Ausgang des Antriebsinverters sowie am AC-Ausgang des Antriebsinverters in Hybrid- und Elektrofahrzeugen
Kerne für Stromtransformatoren in elektronischen Energiezählern
Nanokristalline und amorphe Kerne für sehr kleine Amplitudenfehler auch unter DC-Vorspannung
Niedriger und konstanter Leistungsfehler für verschiedene Lastbedingungen
Verschiedene Standardtypen in der Tabelle unten
Kerne für Fehlerstromschutzschalter (FI)
Unsere Expertise für magnetische Materialien und langjährige Anwendungserfahrung hat eine breite Palette an innovativen Lösungen auf Basis nanokristalliner Kerne hervorgebracht. Diese haben insbesondere ihren Weg in den Markt für Fehlerstromschutzschalter gefunden.
Unser Leistungsporfolio umfasst:
- Bestmögliche Auslegung des Kerndesigns in enger Abstimmung mit unseren Kunden
- Technischer Support mit Simulationssoftware für Optimierungen am Schaltungsdesign
- Sonderkonstruktionen auf Anfrage
- Großserien-Kernproduktion an unseren Standorten in der Slowakei und in Malaysia
In unseren Kernen verwendete Legierungen
| VITROPERM 500 | Fe-basierte nanokristalline Legierung mit höchster magnetischer Permeabilität und einer Sättigungsinduktion von 1,24 T |
| VITROPERM 550 HF | Fe-basierte nanokristalline Legierung mit verbesserter Hochfrequenz-Performance, höchster magnetischer Permeabilität und einer Sättigungsinduktion von 1,24 T |
| VITROPERM 712 | Fe-basierte nanokristalline Legierung mit einer Permeabilität von µ = 12.000 und einer Sättigungsinduktion von 1,23 T |
| VITROPERM 250 | Fe-basierte nanokristalline Legierung mit niedriger Permeabilität (µ = 3.000 - 5.000) und einer Sättigungsinduktion von 1,2 T |
| VITROVAC |
Co-basierte amorphe Legierung mit höchster magnetischer Permeabilität und einer Sättigungsinduktion von ≤ 1,0 T |
Liste von Standardkernen
Begrenzender Außendurchmesser: 11 - 200 mm
Begrenzender Innendurchmesser: 5.1 - 149 mm
Begrenzende
Höhe: 0.16 - 30.5 mm
Höhe: 0.16 - 30.5 mm
| Produkt | Download |
da [mm] |
di [mm] |
h [mm] |
Da [mm] |
Di [mm] |
H [mm] |
Kernform |
AFe [cm2] |
LFe cm |
mFe [g] |
AL 10 kHz [µH] |
Icm 10 kHz [A] |
AL 100 kHz [µH] |
Icm 100 kHz [A] |
Anwendung | Legierung | grade | mechanicalProtection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L2009-W914 | 9.8 | 6.5 | 4.5 | 11.2 | 5.1 | 5.8 | toroidal | 0.06 | 2.6 | 1.1 | 25.5 | 0.14 | 6.4 | 0.3 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2012-W902 | 12 | 8 | 4.5 | 14.1 | 6.6 | 6.3 | toroidal | 0.07 | 3.1 | 1.7 | 28 | 0.15 | 6.8 | 0.31 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2012-W498 | 12.5 | 10 | 5 | 14.3 | 8.5 | 7 | toroidal | 0.05 | 3.5 | 1.3 | 10 | 0.3 | 3.6 | 0.56 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2014-V098 | 14.4 | 11.4 | 3.2 | 16.5 | 9.6 | 5 | toroidal | 0.04 | 4.1 | 1.1 | 10.5 | 0.21 | 2.6 | 0.44 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2015-W865 | 15 | 10 | 4.5 | 17.1 | 7.9 | 6.5 | toroidal | 0.09 | 3.9 | 2.6 | 27 | 0.2 | 6.7 | 0.41 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2016-W403 | 16 | 10 | 6 | 17.9 | 8.1 | 8.1 | toroidal | 0.14 | 4.1 | 4 | 43 | 0.2 | 10.1 | 0.41 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2016-W308 | 16 | 10 | 6 | 17.9 | 8.1 | 8.1 | toroidal | 0.14 | 4.1 | 4 | 11.7 | 1.2 | 6.5 | 1.7 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2016-V165 | 16 | 10 | 6 | 17.9 | 8.1 | 8.1 | toroidal | 0.14 | 4.1 | 4 | N/A | 5.4 | 2 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2017-W515 | 17.5 | 12.6 | 6 | 19.2 | 10.9 | 8.1 | toroidal | 0.12 | 4.7 | 4.1 | 30 | 0.23 | 6.9 | 0.48 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2019-V184 | 19 | 15 | 5 | 21.2 | 13 | 7.3 | toroidal | 0.08 | 5.3 | 3.1 | 18 | 0.26 | 4.4 | 0.54 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2019-W838 | 19 | 15 | 10 | 21.2 | 13 | 12.3 | toroidal | 0.16 | 5.3 | 6.3 | 36.1 | 0.26 | 8.8 | 0.54 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2020-W409 | 20 | 12.5 | 8 | 22.6 | 10.3 | 10.2 | toroidal | 0.24 | 5.1 | 9 | 55.2 | 0.25 | 13.6 | 0.51 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2020-W450 | 20 | 12.5 | 8 | 22.6 | 10.3 | 10.2 | toroidal | 0.24 | 5.1 | 9 | 14.3 | 1.5 | 9.1 | 2.2 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2025-W523 | 25 | 20 | 10 | 27.6 | 17.4 | 12.8 | toroidal | 0.2 | 7.1 | 10 | 28.4 | 0.41 | 7.3 | 0.84 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2025-W380 | 25 | 16 | 10 | 27.9 | 13.6 | 12.5 | toroidal | 0.4 | 6.4 | 17 | 67 | 0.32 | 15.5 | 0.65 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2025-W451 | 25 | 16 | 10 | 27.9 | 13.6 | 12.5 | toroidal | 0.4 | 6.4 | 17 | 17.1 | 1.8 | 11.5 | 2.7 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2025-V349 | 25 | 16 | 10 | 27.9 | 13.6 | 12.5 | toroidal | 0.4 | 6.4 | 17 | 8.6 | 3.23 | 7.58 | 3.67 | motor protection, EMC | VITROPERM 712 | industrial | plastic casing | |
| L2025-W980 | 25 | 16 | 10 | 27.9 | 13.6 | 12.5 | toroidal | 0.4 | 6.4 | 17 | N/A | 9.6 | 3.1 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2030-W423 | 30 | 20 | 10 | 32.8 | 17.6 | 12.5 | toroidal | 0.4 | 7.9 | 23 | 59.3 | 0.5 | 14 | 1 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2030-W358 | 30 | 20 | 10 | 32.8 | 17.6 | 12.5 | toroidal | 0.4 | 7.9 | 23 | 15.5 | 2.1 | 11.1 | 3.1 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2030-W981 | 30 | 20 | 10 | 32.8 | 17.6 | 12.5 | toroidal | 0.4 | 7.9 | 23 | N/A | 11.8 | 2.8 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2040-W422 | 40 | 32 | 15 | 43.1 | 28.7 | 18.5 | toroidal | 0.46 | 11.3 | 38 | 48 | 0.55 | 11.3 | 1.1 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2040-V113 | 40 | 32 | 15 | 43.1 | 28.7 | 18.5 | toroidal | 0.46 | 11.3 | 38 | 13 | 3 | 8.4 | 4.6 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2040-W452 | 40 | 32 | 15 | 43.1 | 28.7 | 18.5 | toroidal | 0.46 | 11.3 | 38 | 10.2 | 3.8 | 7.9 | 5.2 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2040-W964 | 40 | 32 | 15 | 43.1 | 28.7 | 18.5 | toroidal | 0.46 | 11.3 | 38 | N/A | 17 | 2.2 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2040-W424 | 40 | 25 | 15 | 43.1 | 22.5 | 18.5 | toroidal | 0.9 | 10.2 | 64 | 99 | 0.5 | 23.1 | 1 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2040-W453 | 40 | 25 | 15 | 43.1 | 22.5 | 18.5 | toroidal | 0.9 | 10.2 | 64 | 25 | 2.9 | 17.2 | 4.4 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2040-V296 | 40 | 25 | 15 | 43.1 | 22.5 | 18.5 | toroidal | 0.9 | 10.2 | 66 | 12.9 | 5.12 | 11.4 | 5.84 | motor protection, EMC | VITROPERM 712 | industrial | plastic casing | |
| L2045-V102 | 45 | 30 | 15 | 48.3 | 26.4 | 18.2 | toroidal | 0.86 | 11.8 | 74 | 87.6 | 0.59 | 20 | 1.2 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2045-V118 | 45 | 30 | 15 | 48.3 | 26.4 | 18.2 | toroidal | 0.86 | 11.8 | 74 | 24.3 | 3 | 15.8 | 4.6 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2045-V101 | 45 | 30 | 15 | 48.3 | 26.4 | 18.2 | toroidal | 0.86 | 11.8 | 74 | 15.7 | 4.6 | 14.1 | 5.9 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2050-W516 | 50 | 40 | 20 | 53.5 | 36.3 | 23.4 | toroidal | 0.76 | 14.1 | 79 | 45 | 1 | 13.5 | 2 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2050-W565 | 50 | 40 | 20 | 53.5 | 36.3 | 23.4 | toroidal | 0.76 | 14.1 | 79 | 18 | 3.6 | 10 | 5.5 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2050-V146 | 50 | 40 | 20 | 53.5 | 36.6 | 23.4 | toroidal | 0.76 | 14.1 | 79 | 11.7 | 5.5 | 10 | 7.1 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2050-V166 | 50 | 40 | 20 | 53.5 | 36.6 | 23.4 | toroidal | 0.76 | 14.1 | 79 | N/A | 21 | 3 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2054-V172 | 54 | 40 | 20 | 57.5 | 37.7 | 24.1 | toroidal | 1.06 | 14.8 | 115 | 87 | 0.72 | 19.9 | 1.5 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2054-V178 | 54 | 40 | 20 | 57.5 | 37.7 | 24.1 | toroidal | 1.06 | 14.8 | 115 | 24 | 3.7 | 15.7 | 5.8 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2063-W517 | 63 | 50 | 25 | 67.3 | 46.5 | 28.6 | toroidal | 1.2 | 17.8 | 161 | 59 | 1.2 | 17.5 | 2.5 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2063-V110 | 63 | 50 | 25 | 67.3 | 46.5 | 28.6 | toroidal | 1.2 | 17.8 | 161 | 23.3 | 4.5 | 13.8 | 6.9 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2063-V144 | 63 | 50 | 25 | 67.3 | 46.5 | 28.6 | toroidal | 1.2 | 17.8 | 161 | 15.1 | 6.9 | 13.5 | 8.9 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2063-V348 | 63 | 50 | 25 | 67.3 | 46.5 | 28.6 | toroidal | 1.2 | 17.8 | 163 | 10.6 | 8.9 | 9.3 | 10.1 | motor protection, EMC | VITROPERM 712 | industrial | plastic casing | |
| L2063-W985 | 63 | 50 | 25 | 67.3 | 46.5 | 28.6 | toroidal | 1.2 | 17.8 | 163 | N/A | 31 | 3.2 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2080-V140 | 80 | 50 | 20 | 85.8 | 44.6 | 25.5 | toroidal | 2.3 | 20.4 | 342 | 94 | 1.4 | 28 | 2.8 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2080-W531 | 80 | 50 | 20 | 86 | 44.7 | 25.7 | toroidal | 2.3 | 20.4 | 342 | 35 | 5.5 | 24 | 8.4 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2080-V091 | 80 | 50 | 20 | 86 | 44.7 | 25.7 | toroidal | 2.3 | 20.4 | 347 | N/A | 28 | 9.2 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2090-W518 | 90 | 60 | 20 | 95.4 | 54.7 | 24.7 | toroidal | 2.3 | 23.6 | 395 | 81 | 1.7 | 25.1 | 3.3 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2090-V173 | 90 | 60 | 20 | 95.4 | 54.7 | 24.7 | toroidal | 2.3 | 23.6 | 400 | 32.5 | 5.9 | 21.1 | 9.1 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2090-W984 | 90 | 60 | 20 | 95.4 | 54.7 | 24.7 | toroidal | 2.3 | 23.6 | 400 | N/A | 42 | 4.5 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2100-V082 | 100 | 80 | 25 | 105.5 | 75 | 29.6 | toroidal | 1.9 | 28.3 | 379 | 56.3 | 2 | 16.9 | 3.9 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2100-V081 | 100 | 80 | 25 | 105.5 | 75 | 29.6 | toroidal | 1.9 | 28.3 | 379 | 14.6 | 11 | 13.1 | 14 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2102-W468 | 102 | 76 | 25 | 108.1 | 70 | 30.3 | toroidal | 2.5 | 28 | 508 | 55 | 2.7 | 21.6 | 4.9 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2102-V080 | 102 | 76 | 25 | 108.1 | 70 | 30.3 | toroidal | 2.5 | 28 | 508 | 19.1 | 11 | 17.2 | 14 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2102-V347 | 102 | 76 | 25 | 108.1 | 70 | 30.3 | toroidal | 2.5 | 28 | 514 | 13.4 | 14.1 | 11.8 | 16 | motor protection, EMC | VITROPERM 712 | industrial | plastic casing | |
| L2102-W947 | 102 | 76 | 25 | 108.1 | 70 | 30.3 | toroidal | 2.5 | 28 | 515 | N/A | 49 | 4.2 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2016-W620 | 16 | 12.5 | 6 | 17.8 | 10.7 | 8 | toroidal | 0.08 | 4.5 | 2.6 | 15 | 0.5 | 4.8 | 0.63 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2016-W619 | 16 | 12.5 | 6 | 17.8 | 10.7 | 8 | toroidal | 0.08 | 4.5 | 2.6 | 6 | 1.1 | 3.9 | 1.7 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2022-W868 | 22 | 17 | 10 | 24 | 15.2 | 12 | toroidal | 0.2 | 6.1 | 9 | 27.4 | 0.4 | 5.3 | 0.86 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2030-W911 | 30 | 20 | 10 | 32.5 | 17.8 | 12.5 | toroidal | 0.4 | 7.9 | 23.1 | 56 | 0.6 | 13.4 | 0.87 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2040-W624 | 40 | 32 | 15 | 42.3 | 29.1 | 17.8 | toroidal | 0.44 | 11.3 | 36 | 32.5 | 1.1 | 10.3 | 1.6 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2040-W623 | 40 | 32 | 15 | 42.3 | 29.1 | 17.8 | toroidal | 0.44 | 11.3 | 36 | 13 | 2.8 | 8.4 | 4.4 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2045-W886 | 45 | 32 | 15 | 47.3 | 29.8 | 17.8 | toroidal | 0.71 | 12.1 | 63.3 | 19.7 | 3 | 12.8 | 4.7 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2050-W626 | 50 | 40 | 20 | 52.3 | 37.1 | 22.8 | toroidal | 0.73 | 14.1 | 76 | 43 | 1.4 | 13.8 | 2 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2050-W583 | 50 | 40 | 20 | 52.3 | 37.1 | 22.8 | toroidal | 0.73 | 14.1 | 76 | 11.2 | 5.5 | 10 | 7.1 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2063-W627 | 63 | 50 | 20 | 65.5 | 46.6 | 22.8 | toroidal | 0.95 | 17.8 | 124 | 18 | 4.5 | 11.7 | 6.9 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2063-W721 | 63 | 50 | 20 | 65.5 | 46.6 | 22.8 | toroidal | 0.95 | 17.8 | 124 | 13.5 | 6.9 | 12.1 | 8.9 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2080-W628 | 80 | 63 | 20 | 83 | 59.5 | 22.8 | toroidal | 1.24 | 22.5 | 205 | 18.5 | 5.7 | 12 | 8.7 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2080-W722 | 80 | 63 | 20 | 83 | 59.5 | 22.8 | toroidal | 1.24 | 22.5 | 205 | 12 | 8.7 | 10.8 | 11 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2100-W629 | 100 | 80 | 20 | 104 | 75 | 23 | toroidal | 1.46 | 28.3 | 303 | 17.3 | 7.1 | 11.2 | 11 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2100-W723 | 100 | 80 | 20 | 104 | 75 | 23 | toroidal | 1.46 | 28.3 | 303 | 11.2 | 11 | 10 | 14 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2130-W567 | 130 | 100 | 25 | 134.5 | 95 | 28.5 | toroidal | 2.85 | 36.1 | 757 | 50 | 3.4 | 19.4 | 6.2 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2130-W630 | 130 | 100 | 25 | 134.5 | 95 | 28.5 | toroidal | 2.74 | 36.1 | 727 | 25.4 | 9.1 | 16.5 | 14 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2130-W587 | 130 | 100 | 25 | 134.5 | 95 | 28.5 | toroidal | 2.74 | 36.1 | 727 | 16.4 | 14 | 14.8 | 18 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2160-W631 | 160 | 130 | 25 | 165 | 125 | 28.5 | toroidal | 2.74 | 45.6 | 917 | 20.2 | 11 | 13.1 | 18 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2160-W720 | 160 | 130 | 25 | 165 | 125 | 28.5 | toroidal | 2.74 | 45.6 | 917 | 13 | 18 | 11.7 | 23 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2020-V311 | N/A | N/A | N/A | 23 | 9.8 | 11.1 | toroidal | 0.25 | 5.1 | 9.2 | 20 | 1 | 10.6 | 1.7 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2020-V312 | N/A | N/A | N/A | 23 | 9.8 | 11.1 | toroidal | 0.25 | 5.1 | 9.2 | 59.4 | 0.2 | 13.7 | 0.5 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2025-V313 | N/A | N/A | N/A | 28.1 | 13.1 | 13.1 | toroidal | 0.37 | 6.4 | 17.4 | 23.7 | 1.3 | 12.6 | 2.1 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2025-V314 | N/A | N/A | N/A | 28.1 | 13.1 | 13.1 | toroidal | 0.37 | 6.4 | 17.4 | 70.2 | 0.3 | 16.2 | 0.6 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2030-V315 | N/A | N/A | N/A | 33.1 | 17 | 18.1 | toroidal | 0.58 | 7.9 | 33.6 | 30.5 | 1.6 | 16.2 | 2.6 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2030-V316 | N/A | N/A | N/A | 33.1 | 17 | 18.1 | toroidal | 0.58 | 7.9 | 33.6 | 90.4 | 0.4 | 20.8 | 0.8 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2040-V317 | N/A | N/A | N/A | 43 | 21.9 | 18.1 | toroidal | 0.87 | 10.2 | 65.4 | 35.2 | 2.1 | 18.7 | 3.3 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2040-V318 | N/A | N/A | N/A | 43 | 21.9 | 18.1 | toroidal | 0.87 | 10.2 | 65.4 | 104 | 0.5 | 24 | 1 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2063-V319 | N/A | N/A | N/A | 66.8 | 46.1 | 28.4 | toroidal | 1.23 | 17.8 | 160 | 28.6 | 3.6 | 15.2 | 5.8 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2063-V320 | N/A | N/A | N/A | 66.8 | 46.1 | 28.4 | toroidal | 1.23 | 17.8 | 160 | 85 | 0.8 | 19.6 | 1.7 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2025-V321 | N/A | N/A | N/A | 28.6 | 16.7 | 14.8 | toroidal | 0.2 | 7.1 | 10.6 | 12.1 | 1.4 | 6.4 | 2.3 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2025-V322 | N/A | N/A | N/A | 28.6 | 16.7 | 14.8 | toroidal | 0.2 | 7.1 | 10.6 | 36.4 | 0.3 | 8.3 | 0.7 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2022-V323 | N/A | N/A | N/A | 24.9 | 11.6 | 16 | toroidal | 0.41 | 5.7 | 17.2 | 30 | 1.2 | 15.9 | 1.9 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2022-V324 | N/A | N/A | N/A | 24.9 | 11.6 | 16 | toroidal | 0.41 | 5.7 | 17.2 | 90.6 | 0.3 | 20.6 | 0.6 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2071-V280 | N/A | N/A | N/A | 75.2 | 42.2 | 25 | oval | 1.01 | 16.6 | 123 | 51.3 | 1.2 | 15.2 | 2.3 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2071-V380 | N/A | N/A | N/A | 75.2 | 42.2 | 25 | oval | 1.01 | 16.6 | 123 | 25.3 | 3.4 | 13.4 | 5.4 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2016-W373 | 16 | 10 | 6 | 17.6 | 8.3 | 8 | toroidal | 0.14 | 4.08 | 4.3 | 10 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2020-W374 | 20 | 12.5 | 8 | 22 | 10.5 | 10 | toroidal | 0.24 | 5.11 | 9 | 13 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2025-W375 | 25 | 16 | 10 | 27 | 14 | 12 | toroidal | 0.36 | 6.44 | 17 | 16 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2030-W376 | 30 | 20 | 15 | 32.3 | 17.8 | 17.8 | toroidal | 0.57 | 7.85 | 33 | 20 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2040-W433 | 40 | 25 | 15 | 42.3 | 22.5 | 17.3 | toroidal | 0.86 | 10.2 | 64 | 23 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2050-W434 | 50 | 40 | 20 | 52.3 | 37.1 | 22.8 | toroidal | 0.76 | 14.1 | 79 | 15 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2052-W827 | 52 | 40 | 25 | 54.3 | 37.1 | 27.8 | toroidal | 1.14 | 14.5 | 121 | 22 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2055-V045 | 55 | 40 | 25 | 57.5 | 37.1 | 27.8 | toroidal | 1.43 | 14.9 | 156 | 26 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2063-W435 | 63 | 50 | 25 | 65.6 | 46.6 | 27.8 | toroidal | 1.24 | 17.8 | 161 | 19 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2080-W436 | 80 | 63 | 25 | 83.5 | 59.3 | 27.8 | toroidal | 1.62 | 22.5 | 267 | 20 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2130-W352 | 130 | 100 | 25 | 135.5 | 94.5 | 28.5 | toroidal | 2.85 | 36.1 | 757 | 22 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2160-W758 | 160 | 110 | 25 | 165 | 105 | 28.5 | toroidal | 4.75 | 42.4 | 1480 | 31 | N/A | N/A | N/A | power transformer | VITROPERM 500 | industrial | epoxy coating | |
| E4010-W534 | 10 | 8 | 4 | 11.6 | 6.5 | 5.1 | toroidal | 0.03 | 2.83 | 0.7 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4010-W663 | 10.1 | 6.9 | 4.5 | 11.6 | 5.5 | 6 | toroidal | 0.06 | 2.67 | 1.2 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4010-W728 | 10.7 | 8.2 | 4.5 | 14 | 6.6 | 6.2 | toroidal | 0.05 | 2.97 | 1 | N/A | N/A | N/A | N/A | Magnetic amplifier | VITROVAC | industrial | plastic casing | |
| E4012-W464 | 12.8 | 9.5 | 3.2 | 14.7 | 7.9 | 4.8 | toroidal | 0.04 | 3.5 | 1.1 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4012-W547 | 12 | 8 | 4.5 | 14 | 6.6 | 6.2 | toroidal | 0.07 | 3.14 | 1.7 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4012-W535 | 12.5 | 10 | 5 | 14 | 8.5 | 6.8 | toroidal | 0.05 | 3.53 | 1.4 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4015-W813 | 15 | 10 | 4.5 | 17.1 | 7.9 | 6.5 | toroidal | 0.09 | 3.93 | 2.7 | N/A | N/A | N/A | N/A | Magnetic amplifier | VITROVAC | industrial | plastic casing | |
| E4019-W666 | 19.2 | 12.7 | 6 | 20.6 | 11.4 | 7.4 | toroidal | 0.16 | 5.01 | 6.2 | N/A | N/A | N/A | N/A | Magnetic amplifier | VITROVAC | industrial | plastic casing | |
| E4019-W539 | 19 | 15 | 5 | 21.2 | 13 | 7.3 | toroidal | 0.08 | 5.34 | 3.3 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4019-W540 | 19 | 15 | 10 | 21.2 | 13 | 12.3 | toroidal | 0.16 | 5.34 | 6.6 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4020-W538 | 20 | 12.5 | 8 | 22.6 | 10.3 | 10.2 | toroidal | 0.24 | 5.1 | 9.4 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4025-W542 | 25 | 20 | 10 | 27.7 | 17.1 | 12.9 | toroidal | 0.2 | 7.1 | 10.9 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4030-W543 | 30 | 20 | 10 | 32.8 | 17.6 | 12.5 | toroidal | 0.4 | 7.85 | 24.2 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4040-W544 | 40 | 25 | 15 | 43.1 | 22.4 | 18.5 | toroidal | 0.9 | 10.2 | 70.8 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| E4040-W545 | 40 | 32 | 15 | 43.3 | 28.8 | 18.3 | toroidal | 0.48 | 11.3 | 41.8 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| L2010-W759 | 10 | 7 | 4.5 | 11.7 | 5.5 | 6.1 | toroidal | 0.05 | 2.67 | 1.1 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2011-W760 | 11 | 8 | 4.5 | 14.1 | 6.6 | 6.3 | toroidal | 0.05 | 2.98 | 1.2 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2012-W761 | 12 | 8 | 4.5 | 14.1 | 6.6 | 6.3 | toroidal | 0.07 | 3.14 | 1.7 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2012-W762 | 12.5 | 10 | 4.5 | 14.1 | 8.5 | 6.8 | toroidal | 0.05 | 3.53 | 1.2 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2012-W803 | 12.8 | 9.5 | 3.2 | 14.7 | 7.9 | 4.8 | toroidal | 0.04 | 3.5 | 1.1 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2016-W763 | 16 | 10 | 6 | 18 | 8 | 8.1 | toroidal | 0.14 | 4.08 | 4.3 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2016-W764 | 16.5 | 12.5 | 6 | 19.1 | 10.9 | 8.1 | toroidal | 0.1 | 4.56 | 3.2 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2019-W766 | 19 | 15.2 | 4.5 | 21.2 | 12.9 | 7.2 | toroidal | 0.07 | 5.37 | 2.7 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2020-W767 | 20 | 15 | 8 | 22.6 | 10.3 | 10.2 | toroidal | 0.16 | 5.5 | 6.5 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2020-W768 | 20 | 12.5 | 8 | 22.6 | 10.3 | 10.2 | toroidal | 0.24 | 5.11 | 9 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROPERM 500 | industrial | plastic casing | |
| L2022-W836 | 22.3 | 17.3 | 6.2 | 23.8 | 15.8 | 7.8 | toroidal | 0.12 | 6.22 | 5.67 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2025-W835 | 25 | 20 | 6.2 | 26.5 | 18.6 | 7.8 | toroidal | 0.12 | 7.07 | 6.4 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROPERM 500 | industrial | epoxy coating | |
| L2019-W979 | 19 | 15 | 6.2 | 20.5 | 13.6 | 7.8 | toroidal | 0.1 | 5.34 | 3.89 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROPERM 500 | industrial | epoxy coating | |
| E3019-W592 | 19 | 15 | 6.5 | 20.5 | 13.8 | 7.8 | toroidal | 0.1 | 5.34 | 4.3 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROVAC | industrial | epoxy coating | |
| E3019-W800 | 19.7 | 15.3 | 8.3 | 20.9 | 14.1 | 9.6 | toroidal | 0.15 | 5.5 | 6.4 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROVAC | industrial | epoxy coating | |
| E3022-W639 | 22.3 | 17 | 6.5 | 23.4 | 15.8 | 8.1 | toroidal | 0.11 | 6.13 | 5.22 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROVAC | industrial | epoxy coating | |
| E3025-W588 | 25 | 20 | 6.5 | 26.5 | 18.8 | 7.8 | toroidal | 0.13 | 7.07 | 7.3 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROVAC | industrial | epoxy coating | |
| E3031-W774 | 31 | 26 | 6.5 | 32.8 | 24.5 | 8 | toroidal | 0.13 | 8.95 | 9.22 | N/A | N/A | N/A | N/A | 50Hz/60Hz current transformer | VITROVAC | industrial | epoxy coating | |
| L2030-W514 | 30 | 20 | 15 | 32.8 | 17.5 | 17.8 | toroidal | 0.57 | 7.9 | 33 | 88 | 0.38 | 20 | 0.79 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2030-V188 | 30 | 20 | 15 | 32.8 | 17.5 | 17.8 | toroidal | 0.57 | 7.9 | 33 | 26.9 | 1.8 | 16.2 | 2.8 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2030-V129 | 30 | 20 | 15 | 32.8 | 17.5 | 17.8 | toroidal | 0.57 | 7.9 | 33 | 15.7 | 3.1 | 14.1 | 3.9 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2160-V074 | 160 | 130 | 25 | 166.9 | 123.9 | 30.5 | toroidal | 2.7 | 45.6 | 917 | 28 | 8.5 | 14 | 14 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2160-V088 | 160 | 130 | 25 | 166.9 | 123.9 | 30.5 | toroidal | 2.7 | 45.6 | 917 | 20 | 11 | 13.1 | 18 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2160-V066 | 160 | 130 | 25 | 166.9 | 123.9 | 30.5 | toroidal | 2.7 | 45.6 | 917 | 13 | 18 | 11.7 | 23 | EMC | VITROPERM 500 | industrial | plastic casing | |
| L2160-V350 | 160 | 130 | 25 | 116.9 | 123.9 | 30.5 | toroidal | 2.9 | 45.6 | 966 | 9.5 | 22.9 | 8.4 | 26.1 | motor protection, EMC | VITROPERM 712 | industrial | plastic casing | |
| L2160-W982 | 160 | 130 | 25 | 166.9 | 123.9 | 30.5 | toroidal | 2.9 | 45.6 | 970 | N/A | 82 | 2.9 | N/A | motor protection, EMC | VITROPERM 250 | industrial | plastic casing | |
| L2022-W867 | 22 | 17 | 6 | 24 | 15.2 | 8 | toroidal | 0.12 | 6.1 | 5.4 | 16.4 | 0.6 | 4.3 | 0.86 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2025-W622 | 25 | 20 | 10 | 27.3 | 17.5 | 12.3 | toroidal | 0.19 | 7.1 | 9.9 | 22.5 | 0.7 | 7.2 | 0.99 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2025-W621 | 25 | 20 | 10 | 27.3 | 17.5 | 12.3 | toroidal | 0.19 | 7.1 | 9.9 | 9 | 1.7 | 5.8 | 2.8 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2030-W676 | 30 | 25 | 15 | 32.3 | 22.7 | 17.5 | toroidal | 0.27 | 8.6 | 17.4 | 26.5 | 0.9 | 8.5 | 1.2 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2194-V105 | 194 | 155 | 25 | 200 | 149 | 28.5 | toroidal | 3.71 | 54.8 | 1490 | 45 | 4.9 | 14.7 | 9.1 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| L2194-W908 | 194 | 155 | 25 | 200 | 149 | 28.5 | toroidal | 3.71 | 54.8 | 1490 | 15 | 21 | 13.2 | 27 | EMC | VITROPERM 500 | industrial | epoxy coating | |
| E4025-W541 | 25 | 16 | 10 | 27.9 | 13.6 | 12.5 | toroidal | 0.36 | 6.44 | 17.9 | N/A | N/A | N/A | N/A | Magnetic amplifier, Spike Blocker | VITROVAC | industrial | plastic casing | |
| L2025-V344 | 25 | 16 | 10 | 27.9 | 13.6 | 12.5 | toroidal | 0.4 | 6.4 | 17 | 69.9 | 0.3 | 24 | 0.6 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2040-V345 | 40 | 25 | 15 | 43.1 | 22.5 | 18.5 | toroidal | 0.9 | 10.2 | 65 | 100.6 | 0.5 | 36.1 | 1 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2102-V346 | 102 | 76 | 25 | 108.1 | 70 | 30.3 | toroidal | 2.4 | 28 | 492 | 91.4 | 1.5 | 36 | 2.8 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2104-V281 | N/A | N/A | N/A | 108.3 | 42.2 | 25 | oval | 1.01 | 23.2 | 172 | 36.7 | 1.6 | 10.8 | 3.2 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2063-V384 | 63 | 50 | 25 | 67.3 | 46.5 | 28.6 | toroidal | 1.2 | 17.7 | 156 | 76.2 | 0.92 | 28.7 | 1.73 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2104-V381 | N/A | N/A | N/A | 108.3 | 42.2 | 25 | oval | 1.01 | 23.2 | 172 | 18.1 | 4.7 | 9.56 | 7.6 | EMC | VITROPERM 500 | automotive | plastic casing | |
| L2030-V376 | 30 | 20 | 10 | 33 | 17.6 | 12.5 | toroidal | 0.39 | 7.85 | 22.4 | 58.9 | N/A | 21.2 | 0.74 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2009-P001 | 9.8 | 6.5 | 4.5 | 11 | 5.1 | 5.8 | toroidal | 0.06 | 2.56 | 1.09 | 25.6 | 0.13 | 9.63 | 0.25 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2012-P002 | 12 | 8 | 4.5 | 14.1 | 6.6 | 6.3 | toroidal | 0.07 | 3.14 | 1.62 | 25.3 | 0.16 | 9.48 | 0.3 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2017-P003 | 17.5 | 12.6 | 6 | 19.2 | 10.9 | 8.1 | toroidal | 0.12 | 4.73 | 3.98 | 27.4 | 0.24 | 10.3 | 0.46 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2019-P004 | 19 | 15 | 10 | 21.2 | 13 | 12.3 | toroidal | 0.16 | 5.34 | 6.12 | 33 | 0.28 | 12.4 | 0.52 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2020-P005 | 20 | 12.5 | 8 | 22.6 | 10.3 | 10.2 | toroidal | 0.23 | 5.11 | 8.78 | 51.8 | 0.26 | 19.5 | 0.5 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2040-P006 | 40 | 32 | 15 | 43.1 | 28.7 | 18.5 | toroidal | 0.45 | 11.3 | 37.4 | 45 | 0.55 | 16.9 | 1.06 | EMC | VITROPERM 550 HF | industrial | plastic casing | |
| L2020-V412 | N/A | N/A | N/A | 23.2 | 9.8 | 11.1 | toroidal | 0.24 | 5.1 | 9 | 59 | 0.2 | 20.2 | 0.5 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2025-V414 | N/A | N/A | N/A | 28.1 | 13.1 | 13.1 | toroidal | 0.36 | 6.4 | 17 | 71.2 | 0.3 | 24.4 | 0.6 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2030-V416 | N/A | N/A | N/A | 33.1 | 17 | 18.1 | toroidal | 0.57 | 7.8 | 33 | 94.4 | 0.4 | 31.7 | 0.7 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2040-V418 | N/A | N/A | N/A | 43 | 22 | 18 | toroidal | 0.86 | 10.2 | 64 | 103.1 | 0.5 | 36.2 | 0.9 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2063-V420 | N/A | N/A | N/A | 66.75 | 46.1 | 28.35 | toroidal | 1.23 | 17.7 | 156 | 58.8 | 1.2 | 28.5 | 2.1 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2025-V422 | N/A | N/A | N/A | 28.5 | 16.7 | 14.8 | toroidal | 0.2 | 7.1 | 10 | 35.7 | 0.3 | 12 | 0.6 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2022-V424 | N/A | N/A | N/A | 24.9 | 11.6 | 0.16 | toroidal | 0.39 | 5.75 | 16 | 86.6 | 0.3 | 29.1 | 0.5 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2058-V398 | N/A | N/A | N/A | 62 | 44.8 | 20 | oval | 0.57 | 12.3 | 51 | 39.1 | 0.9 | 18.9 | 1.5 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2071-V480 | N/A | N/A | N/A | 75.2 | 55 | 25 | oval | 0.97 | 16.6 | 118 | 48.6 | 1.16 | 23.8 | 2 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2104-V481 | N/A | N/A | N/A | 108.22 | 88 | 22 | oval | 0.97 | 23.2 | 165 | 34.7 | 1.62 | 17 | 2.8 | EMC | VITROPERM 550 HF | automotive | plastic casing | |
| L2045-V427 | 45 | 30 | 15 | 48.4 | 26.9 | 18.2 | toroidal | 0.84 | 11.8 | 73.1 | 81 | 0.61 | 30.4 | 1.15 | EMC | VITROPERM 550 HF | industrial | plastic casing |
Kernbaugruppen mit nanokristallinen Kernen
Einleiterdrosseln aus vormontierten, gestapelten nanokristallinen Ringkernen sind eine einfach zu installierende und effektive
Lösung für Lagerstromprobleme oder aufgrund anderer Ursachen auftretender extrem hoher Common Mode Störströme in Großumrichtern, in Windgeneratoren und anderen Anwendungsfeldern.
Hier treten oft durch Resonanzerscheinungen hervorgerufene Störströme mit hoher Amplitude auf (Peakwerte einige 10 A bis über 100 A), meist in Form kurzer d.h. hochfrequenter Stromspitzen. Für diese Anwendungen bietet VAC konfektionierte Kernstapel an, die sich mit geringem Aufwand einfach und sicher in bestehende Anwendungen integrieren lassen.
Die Kernbaugruppen sind in zwei Baugrößen mit zwei unterschiedlichen Abmessungen der Leitungsdurchführungen verfügbar. Die
Kernstapel werden projektspezifisch konfektioniert, wobei die Anzahl der gestapelten Kerne (bis 7 St.) und die jeweiligen Kerntypen
der benötigten Induktivität und der jeweiligen Ableit- oder Common Mode Ströme als sättigungsfeste Auslegung angepasst werden.
Die Tabelle unten zeigt die bestehenden Kernstapel. Weitere Varianten auf Anfrage.
Tabelle bestehender Kernbaugruppen
Nom. Kernbaugruppe Abmessung Länge: 140 - 310 mm
Nom. Kernbaugruppe Abmessung Breite: 120 - 180 mm
Nom. Kernbaugruppel Abmessung Höhe: 130 - 190 mm
| Produkt | Download |
da [mm] |
di [mm] |
h [mm] |
Länge | Breite | Höhe |
AL 10 kHz [µH] |
Icm 10 kHz [A] |
AL 100 kHz [µH] |
Icm 10 kHz [A] |
|---|---|---|---|---|---|---|---|---|---|---|---|
| L2102-W075 | 102 | 76 | 25 | 140 | 120 | 130 | 9.1 | 48 | 8.4 | 49 | |
| L2102-W078 | 102 | 76 | 25 | 300 | 120 | 130 | 416 | 2.1 | 130 | 4.1 | |
| L2160-W076 | 160 | 130 | 25 | 261 | 180 | 190 | 16 | 80 | 14.5 | 82 | |
| L2160-W079 | 160 | 130 | 25 | 210 | 180 | 190 | 52 | 18 | 46.8 | 23 | |
| L2160-W080 | 160 | 130 | 25 | 310 | 180 | 190 | 91 | 18 | 81.9 | 23 | |
| L2160-W081 | 160 | 130 | 25 | 240 | 180 | 190 | 65 | 18 | 58.5 | 23 |
Downloads
Verwandte Produkte
Nanokristalline Entstördrosseln
Stromkompensierte Entstördrosseln (CMCs) aus nanokristallinem VITROPERM bieten beste Dämpfungseigenschaften bei kompakten Abmessungen für eine hohe Breite an EMV Anforderungen. Das große Portfolio an Standardtypen hält Lösungen für 1-Phasen und 3-Phasen Systeme sowie 4-fach Drosseln vor.
EMV-Lösungen
Wir bieten nicht nur Hochleistungswerkstoffe für EMV-Lösungen, sondern auch Kerne und stromkompensierte Drosseln auf Basis unseres nanokristallinen VITROPERM-Materials.
Nanokristalline Werkstoffe VITROPERM®
VITROPERM ist ein nanokristalliner Werkstoff auf Eisenbasis mit einer hervorragenden Kombination weichmagnetischer Eigenschaften, die es zum Spitzenmaterial für ein breites Anwendungsspektrum machen.
